FC PC Fiber Optic Connectors

FC PC Fiber Optic Connectors Optico Communication Co., Ltd is one of the leading suppliers of network fiber components supplying FC PC Fiber Optic Connectors in Shenzhen, China. We have devoted to fiber optic industry for over 18 years since 2000. Due to our high quality and best service, our...

Chat Now

FC PC Fiber Optic Connectors

Optico Communication Co., Ltd is one of the leading suppliers of network fiber components supplying FC PC Fiber Optic Connectors in Shenzhen, China. We have devoted to fiber optic industry for over 18 years since 2000. Due to our high quality and best service, our products have successfully exported to more than 30 countries, and our main market are covering most of America, Oceania market. We look forward to establish long-term and mutual-benefit business cooperation with you.

FC PC Fiber Optic Connectors

Product Introduction of the FC PC Fiber Optic Connectors :
Produced with high quality standard, FC PC Fiber Optic Connectors is a design specifically for Europe FTTX network system connection. It is with low insertion loss(IL<=0.2dB)(APC) and high return loss (RL>=60dB)(APC). We have devoted to fiber optic industry for over 18 years since 2000. Due to our high quality and best service, our products have successfully exported to more than 30 countries, and our main market are covering most of America, Oceania market. We look forward to establish long-term and mutual-benefit business cooperation with you.

FC PC Fiber Optic Connectors Specifications:


Insertion Loss<=0.20dB(APC), <=0.30dB(PC)
Return Loss>=60dB(APC), >=50dB(PC)
Durability<=0.20dB typical change, 1000 matings
Operating Temperature-40℃ to +85℃
Ferrule Hole Sizes125.0+1/-0μm, Concentricity: <=0.5μm
125.5+1/-0μm, Concentricity: <=0.5μm
126.0+1/-0μm, Concentricity: <=0.5μm

Features and Applications of FC PC Fiber Optic Connectors :

FEATURES:
Low insertion loss and high return loss
High precision alignment
Nickel plated brass body
Telcordia style boots
Free-floating ceramic ferrule
Precision anti-rotation key and corrosion resistant body

APPLICATIONS:

Telecommunication networks
Local Area Networks (LANs)
Wide Area Networks (WANS)
CATV
Metro
Test equipment
Premise installations
Data processing networks
Active device termination

Product Certificates of the FC PC Fiber Optic Connectors :
Quality Control Standard: Insertion Loss(IL)≤0.2dB(APC), IL<=0.3dB(PC); Return Loss(RL)≥50dB(PC), RL≥65dB(APC);
Certificates: We have passed CPR, ISO, CE certificates; .

Packing Details of FC PC Fiber Optic Connectors :
Suitable quantity per opp bag, suitable quantity per carton, carton size: 46cm x 46cm x 26cm;
Customized packaging and carton service is vailable

Production lead time, Delivery Ways of the FC PC Fiber Optic Connectors :
Production lead time: 7~15 days after deposit;
Delivery way: By International Express e.g. DHL, UPS, Fedex, TNT, etc., or by air, by train, by sea etc;

FAQ of the FC PC Fiber Optic Connectors :
1, Can mix different models in my order?
Yes, you can.
2, Besides fiber optic patch cord, what other fiber optic components do you produce?
Besides fiber patch cord, we also produce fiber optic pigtail, patch cable, PLC splitter, optical ODF, fiber optic cable, optical connector, optical adapter, etc.
3, Can you design products based on our requirements?
Yes, we have R&D team, and we can custom the product according to your requirements.
4, What's  nearest port in your place?
Shenzhen port.
5, What is your annual turnover?
5 million~10 million USD;
6, What is your main market?
Europe, North America, Oceania;
