Telecommunication Networks Fiber Optic Connectors

Telecommunication Networks Fiber Optic Connectors Optical fiber connector connects two optical fibers permanently or separably, it has the protective part i the connection part. The fiber connector is the end device of the fiber.

Telecommunication Networks Fiber Optic Connectors

Optical fiber connector connects two optical fibers permanently or separably, it has the protective part i the connection part. The fiber connector is the end device of the fiber.


The optical fiber interface is the physical interface used to connect the fiber cable.Usually there are several types: SC, ST, FC, etc. FC is the abbreviation of Ferrule Connector. Its external strengthening method is metal sleeve, and its fastening way is the screw. The ST interface is usually used for 10base-F, and the SC interface is usually used for 100base-FX.



fiber connectors 3.jpg


The Telecommunication Networks Fiber Optic Connectors Product Specs:

Insertion Loss<=0.20dB(APC), <=0.30dB(PC)<=0.30dB(PC)
Return Loss>=60dB(APC), >=50dB(PC)
Durability<=0.20dB typical change, 1000 matings
Operating Temperature-40℃ to +85℃-40℃ to +85℃
Ferrule Hole Sizes125.0+1/-0μm, Concentricity: <=0.5μm126μm, Concentricity: <=3.0μm
125.5+1/-0μm, Concentricity: <=0.5μm127μm, Concentricity: <=3.0μm
126.0+1/-0μm, Concentricity: <=0.5μm128μm, Concentricity: <=3.0μm


Introduction of Various Optical Fiber Interface Types:

FC circular thread (most used on the distribution frame);

ST clamping circular type;

SC clamping squared type (most used on router switches);

PC micro-sphere grinding and polishing;

APC is an 8 degree Angle with micro-sphere grinding and polishing;

MT-RJ square, a double fiber transceiver;

Optical fiber module: generally supports hot plug;

GBIC Giga Bitrate Interface Converter, the optical fiber Interface used is mostly SC or ST type.

SFP small encapsulated GBIC, used fiber interface is LC type.


Telecommunication Networks Fiber Optic Connectors Product Characteristics:

APPLICATIONS:
Telecommunication networks
Premise installations
Data processing networks
Local Area Networks (LANs)
Wide Area Networks (WANS)
Test equipment
Active device termination

The Telecommunication Networks Fiber Optic Connectors Product Quality:
Quality Control Standard: Insertion Loss(IL)≤0.2dB(APC), IL<=0.3dB(PC); Return Loss(RL)≥50dB(PC), RL≥65dB(APC);
Certificates: We have passed CPR, ISO, CE certificates;

Delivery way: By International Express e.g. DHL, UPS, Fedex, etc., or by air, by train, by sea etc;
shipping ways.jpg


Company Pictures:

Optico Communication Workshop(1).jpg

fiber optic factory.jpg
