Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of gyts outdoor fiber cable in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
GYTS outdoor fiber optic cable is used for duct and aerial applications. We supply single mode GYTS fiber optical cable and multimode GYTS fiber optic cable, fiber strand from 2 cores to 432 cores. A related GYTA type cable is available. Fiber optic cable GYTS, 2~144 fibers central strength member (steel), jelly filled, fiber contained loose tube and PP filler (if necessary) stranded, water blocking jelly, longitudinally covered by copolymer steel tape, PE outer sheath. G652D SM fiber, detailed specification on your request.
| Tensile(N) | Long term | 600 |
| Short term | 1500 | |
| Crush(N/100mm) | Long term | 300 |
| Short term | 1000 | |
| Min. Bending radius(D=Cable diameter) | Dynamic | 20XD |
| Static | 10xD | |
| Temperature Range(℃） | -20~+60℃ | |
| Fiber Count | 2-32 | 38-60 | 62-72 | 74-96 | 98-120 | 122-216 |
| Cable Diameter | 8.5 | 10.0 | 11.0 | 12.0 | 14.5 | 16.5 |
| Tolerance Range(mm) | +-0.5, or customized | |||||
| Cable Weight(kgs/km) | 120 | 140 | 165 | 200 | 240 | 290 |
Features:
Strong water-resistance Performance
High anti-crush and tensile strength
Application:
LAN, and long distance cabling
Recommended Laying Methods:
Aerial, Duct
