2X8 Sc/APC 0.9mm Steel Tube PLC Splitter

Name: China 1*16 Single Mode Mini PLC Splitter Manufacturers and Suppliers - Factory Wholesale - Optico Communication
Brand: Optico
SKU: 42017138

Description 1*16 Mini PLC Splitter, it features small size, wide operating wavelength range, It is widely used in PON(EPON/GPON) networks. And b lockless PLC splitter has stronger fiber protection, which is a miniaturization result of cassette splitter. Optico provides whole series of 1xN and...

Send Inquiry

1*16 Single Mode Mini PLC Splitter

1*16 Mini PLC Splitter, it features small size, wide operating wavelength range, It is widely used in PON(EPON/GPON) networks. And blockless PLC splitter has stronger fiber protection, which is a miniaturization result of cassette splitter.Optico provides whole series of 1xN and 2xN splitter products that are tailored for specific applications.

Parameters	1x4		1x8	1x16	1x32	1x64
Wavelength(nm)	1260-1650
Insertion Loss (dB)	Max(S/P)	7.4/7.2	10.7/10.5	13.7/13.5	16.9/16.5	21
Loss Uniformity (dB)	Max	0.6	0.8	1.2	1.7	2.5
Return Loss (dB)	Min(S/P)	50/55	50/55	50/55	50/55	50
PDL (dB)	Max	0.2	0.3	0.3	0.3	0.4
Directivity (dB)	Min	55	55	55	55	55
Pigtail Length(m)	1 or customer specified
Fiber Type	SMF -28e or customer specified
Operating Temperature( ℃)	-20~75
Storage Temperature( ℃)	-40~85
Packaging Size(L x W x H)(mm)	40x4x4		40x4x4	40x4x4	50x7x4	60x12x4
