Aerial G657A FRP KFRP Steel Wire 6 Core FTTH Drop Cable
Most of the sheathed fiber optic cables are single-core or double-core structures, and can also be made into a four-core structure. The cross-section is an 8-shaped cross-section. The reinforcement is located at the center of the two circles. The metal or non-metallic structure can be used. The optical fiber is located at the geometric center of the 8-shaped geometry. G.657 small bending radius optical fiber is used for the optical fiber in the sheathed cable, which can be laid with a bending radius of 20mm, which is suitable for entering the house in the way of the pipeline or the wire in the building.
The disc-shaped optical cable for access network (for outdoor wiring) is to place the optical communication unit (optical fiber) in the center, two parallel non-metallic reinforcements (FRP) or metal reinforcements placed on both sides, and finally, extruded black or colored polymer Made of vinyl chloride (PVC) or low-smoke halogen-free material (LSZH, low-smoke, halogen-free, flame retardant).
Place of Origin: Shenzhen, China
Brand Name: OPTICO
Model Number: FTTH drop cable
Type: Outdoor Aerial
Fiber: Single mode G657A1
No. of Fiber: 6
Use: Fiber to the home (FTTH)
Name: Aerial G657A FRP KFRP Steel wire 1 2 4 6 8 10 core FTTH drop cable
Dimension: 2.0*5.0 mm
Strength member: steel wire/FRP/KFRP
Operating temperature: -40 to +70°C
Packing: 2km/roll
Certificate: ISO9001, SGS, ROHS
Application: FTTX/FTTA
Jacket material: LSZH, LSZH, PE
Jacket color: Black, White
Supply Ability: 6000000 Meter/Meters per Month 1 2 4 6 8 10 core FTTH drop cable
The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP) or steel wires are placed at the two sides. A steel wire as the additional strength member is also applied. Then the cable is completed with a black LSZH sheath.
Product Features:
Two parallel FRP strangth members ensuregood performance of crush resistance to protect the fiber
Two parallel FRP strangth members ensuregood performance of crush resistance to protect the fiber
Simple structure ,light weight and high practicability
Novel flute desig,easily strip and splice ,simplify the installation and maintenance
Low smoke zero halogen and flame reardant sheath
Method Entry House:
User outdoor wiring
Vertical and horizontal wiring in the building
Self-supporting overhead indoor wiring
Piping outdoor wiring
Specifications:
Items | Description | |
Number of fiber | 6 cores | |
Fiber type | G657A | |
Strength member | material | Steel wire/FRP/KFRP |
diameter | 2*(0.5~0.8)mm | |
Self support | material | Steel wire |
Messenger wire | diameter | 1.0mm |
Outer sheath | material | LSZH |
diameter | 1.8±0.2mm | |
Cable size (Height * width) | 2.0(±0.1) mm × 5.2(±0.2)mm | |
Cable sheath thickness | Max. 0.8mm/Min. 0.4mm | |
Messenger sheath thickness | 0.5~0.7mm | |
Cable weight | 22KG±1KG | |
Cable Mechanical characteristic:
Items | Description | |
Installation Temperature range | -20--+60°C | |
Operation and transport temperature | -40-+70°C | |
Min Bending Radius(mm) | Long term | 15D |
short term | 30D | |
Allowable Tensile Strength(N) | Long term | 300 |
short term | 600 | |
Crush Load (N/100mm) | Long term | 1000 |
short term | 2200 | |
