Product Profile
The 8F MPO Male To MPO Female Trunk Cable is a versatile, high-performance fiber optic cable designed to meet the demanding connectivity needs of modern data centers and telecommunications networks. It enables efficient and reliable data transmission while providing customization options to suit various applications.
8F fiber MTP cable features high-performance MPO female connectors and 8 corning optical fibers, enabling optimal functionality and reliability.
The connector end face of the fiber optic MPO patch cord is polished with APC/UPC (Ultra Physical Contact).
Therefore, the 8 fiber MTP cable insertion loss is as low as 0.3dB (low loss), 0.35dB (standard loss), and 0.7dB (maximum), which can maintain signal integrity and achieve seamless data communication in meeting the needs of high-bandwidth applications in data centers.
OPTICO also provides special angle customization, and the connector end face angle can be customized to 12°, 9°, etc.
Product specifications
| Physical Properties | Parameter | ||
| Fiber Count | 8/12/16/24/32/48 Fibers / Custom | ||
| Fiber Mode | SM(OS2)/MM(OM3/OM4/OM5) | ||
| Connector Type | US Conec MTP Female/Male; MPO Female/Male | ||
| Polarity | Type A/B/C | ||
| Cable Jacket | PVC/LSZH/OFNP | ||
| Jacket Colour | Yellow/Aqua/Magenta/Lime Green/ Custom | ||
| Cable Diameter(mm) | 3 | ||
| Minimum Bend Radius | 7.5 | ||
| Fiber and Boot Length | Customizable | ||
|
|
|||
| Optical Properties | Parameter | ||
| Insertion Loss(dB) | Standard Loss | Low Loss | Ultra Low Loss |
| ≤0.7 | SM ≤0.35, MM ≤0.5 | ≤0.25 | |
| Return Loss(dB) | SM ≥ 60, MM ≥ 20 | ||
| Wavelength(nm) | SM 1310/1550, MM 850/1300 | ||
| Tensile Strength(N) | Long Term | Short Term | |
| 70N | 220N | ||
| Operating Temperature(°C) | -40 ~ +85 | ||
| Storage Temperature(°C) | -20 ~ +70 | ||
Product features
Space and Cost Efficiency
With the ability to achieve up to 8 times the density of SC connectors, the 8F MPO Male To MPO Female Trunk Cable Customizable SM MM significantly saves space and reduces costs.
Multiple Insertion Loss Options
OPTICO provides the flexibility to choose from three different insertion loss levels for customers to optimize performance based on their specific network requirements.
8 fiber MTP cable offer insertion loss options for standard loss, low loss, and ultra-low loss (≤0.7dB, ≤0.35dB, and ≤0.3dB, respectively), plus a return loss of ≥20 dB to ensure reliable and consistent data transmission.
Ease of Installation and Management
The MPO trunk cable is factory pre-terminated and integrated push-pull tubing to streamline installation, saving time and effort in cable management.
Adherence to Industry Standards
The 8F MPO Male To MPO Female Trunk Cable Customizable SM MM is compliant with IEC 61754-7, TIA/EIA 604-5, Telcordia GR-1435-CORE, and RoHS guidelines.
Applications
High Density Data Center
Backbone Network
Communication Rooms
Production Drawing
OPTICO owns a powerful team of engineers, production instruction drawings, logos, colors, connectors, the number of cores, and other special requirements can be customized.
Welcome to contact us to customize your special requirements.
Connectivity Solutions
25G Trunk Cabling Solution
1. Core Cabling Solution:
a. Core Connection Equipment
Equip with a high-performance switch and 25G SFP28 Optical Transceiver Module, the data transmission rate can reach 25.78 Gb/s.
b. Fiber Connection Method:
Utilize 12 Cores MPO-LC Fanout Fiber Optic Cable or MTP Patch Cord 12 Cores to connect Equipment.
Alternatively, we can use 8F MPO-MPO Female Trunk Cable OM3 to connect.
c. Fiber Cabling Management:
Use 12 Port MTP Panel,and High-Density 1U Rack Mount Enclosure Unloaded Sliding Drawer to store and organize cables to avoid clutter.
2. Core to Access Connection
Apply 24F 2×12 MPO Trunk Cable OM3 Female or 24F MPO-MPO Female Trunk Cable OS2 to connect the core and access.
3. Access Cabling Solution
Same as the core cabling solution.
Certificates
CE
CPR
ISO
RoHS
Full Ranges Of Reliability Tests From Third-party Lab
Coupling Test
Drop Test
Durability Test
High-Constant Temperature and Humidity Test
High-Low Temperature Test
Loss Test
Micro Cross Section Inspection Test
Resistant to Repeated Bending Test
Single Vertical Burning Test
Temperature Change Test
UV Test
delivery(7-15 days)
