Product Profile
Telecommunication Fiber Optic Adapter is a device used to connect two fiber optic connectors together, enabling reliable and efficient data transmission in telecommunications networks. It is a small but crucial component in fiber optic systems, providing a stable and secure connection between fiber optic cables.
OPTICO Company is committed to providing high-quality fiber optic adapters that are not only easy to install and use, but also durable and corrosion-resistant. We can guarantee that our telecommunication fiber optic adapters meet industry standards and go above and beyond client requirements.
Product Features
High Precision
Low Insertion loss
Easy to Install and Use: The Telecommunication Fiber Optic Adapter features a simple and user-friendly design with snap-in or screw-on coupling mechanism.
Durable and Corrosion-resistant Housing: It is made of ceramic or medal for long-term use in various environments.
RoHS compliant and made with high-quality materials for maximum performance
High Reliability and Stability
Diversity: OPTICO’s optic adapters are available in various types, including FC, SC, ST, LC, and MPO/MTP, to fit different fiber optic connector types.
Specifications
| Adapter Type |
SC/LC-SC/LC |
FC/ST-FC/ST | MTP/MPO-MTP/MPO |
| Material | PBT/PC | Metal | PBT/PC |
| Insertion loss | ≤0.2dB | ≤0.2dB | ≤0.2dB |
| Durability | ≤0.2dB typical change,1000 matings | ≤0.2dB typical change,1000 matings | ≤0.2dB typical change,1000 matings |
| Operating Temperature | -40~+85℃ | -40~+85℃ | -40~+85℃ |
| Storage Temperature | -40~+85℃ | -40~+85℃ | -40~+85℃ |
| Ferrule Hole Sizes | 125.0+1/-0um, Concentricity:≤0.5um | 125.0+1/-0um,Concentricity:≤0.5um | 125.0+1/-0um,Concentricity:≤0.5um |
| 125.5+1/-0um, Concentricity:≤0.5um | 125.5+1/-0um,Concentricity:≤0.5um | 125.5+1/-0um,Concentricity:≤0.5um | |
| 126.0+1/-0um, Concentricity:≤0.5um | 126.0+1/-0um,Concentricity:≤0.5um | 126.0+1/-0um,Concentricity:≤0.5um |
Applications
FTTH Network
CATV Network
LAN Network
Ordering Information
| Connector Type | Surface type | Fiber count | Fiber type | Housing material | Flange or not | Shutter or not |
| 1=SC | 1=UPC | 1=Simpex | 1=SM | 1=PC | 1=Yes | 1=Yes |
| 2=LC | 2=APC | 2=Duplex | 2=MM | 2=PBT | 2=No | 2=No |
| 3=FC | 3=Triplex | 3=Metal | ||||
| 4=ST | 4=Quadruplex | S=Custom | ||||
| 5=E2000 | 5=Custom | |||||
| 6=MTP | ||||||
| 7=MPO | ||||||
| S=Custom |
