FTTH GEPON OLT
Quick Details
Place of Origin: Guangdong, China (Mainland)
Brand Name: OPTICO
Model Number: V1600D4
Uplink interface: 4*10/100/1000M auto-negotiation
Connector Type: 1000BASE-PX20+/PX20++
Transmission Distance: 20KM/40KM
SFP (independent): 4*SFP or 4*SFP+ slots (SFP+ is 10GE)
EPON port speed: Symmetrical 1.25Gbps
Max splitting ratio: 1:64
Weight: 4.2kg
Power Consumption: 30W
Working Temperature: -10~+55℃
Dimension: 442mm*200mm*43.6mm
FTTH GEPON OLT Packaging & Delivery:
Packaging Details;
standard package with carton box;
530mm*444mm*127mm, 6KG for one piece;
547mm*461mm*422mm, 19.5KG for three pieces.
Delivery Time
Within 2-30 work days
FTTH GEPON OLT Introduction
V1600D series EPON OLT products are 1U height 19 inch rack mount products. The features of the OLT are small, convenient, flexible, easy to deploy, high performance. It is appropriate to be deployed in compact room environment. The OLTs can be used for “TriplePlay”, VPN, IP Camera, Enterprise LAN and ICT applications. There are three members in this series, V1600D2, V1600D4 and V1600D8.
V1600D4provides 4GE(copper) and4SFP slots independent interface for uplink, and 4*EPON OLT ports for downstream. It can support 128 ONUs under 1:64 splitter ratio.
FTTH GEPON OLT Technical Specifications:
Item | V1600D4 | |
Chassis | Rack | 1U 19 inch standard box |
1000M | QTY | 8 |
Uplink Port | Copper | 4*10/100/1000M auto-negotiation |
SFP | 4*SFP or 4*SFP+ slots | |
(independent) | (SFP+ is 10GE) | |
EPON Port | QTY | 4 |
Physical Interface | SFP Slots | |
Connector Type | 1000BASE-PX20+ | |
Max splitting ratio | 0.086111111 | |
Management Ports | 1*10/100BASE-T out-band port, 1*CONSOLE port | |
PON Port Specification | Transmission Distance | 20KM |
EPON port speed | Symmetrical 1.25Gbps | |
Wavelength | TX 1490nm, RX 1310nm | |
Connector | SC/PC | |
Fiber Type | 9/125μm SMF | |
TX Power | +2~+7dBm | |
Rx Sensitivity | -27dBm | |
Saturation Optical Power | -6dBm |
FTTH GEPON OLT Functions:
Management Mode | SNMP, Telnet and CLI |
Management Function | Fan Group Detecting; |
Port Status monitoring and configuration management; | |
Layer2 switch configuration such as VLAN, Trunk, RSTP, IGMP, QOS, etc; | |
EPON management function: DBA,ONU authorization, ACL, QOS, etc; | |
Online ONU configuration and management; | |
User management; | |
Alarm management. | |
Layer2 Switch | Support port VLAN and protocol VLAN; |
Support 4096 VLANs; | |
Support VLAN tag/Un-tag ,VLAN transparent transmission, QinQ; | |
Support IEEE802.3d trunk; | |
Support RSTP; | |
QOS based on port, VID, TOS and MAC address; | |
IGMP Snooping; | |
IEEE802.x flow control; | |
Port stability statistic and monitoring. | |
Layer 3 Route | 1024 Host Routes; |
512 Subnet Routes; | |
256 IP Multicast Groups; | |
EPON Function | Support port-based rate limitation and bandwidth control; |
In compliant with IEEE802.3ah standard; | |
Up to 20KM transmission Distance; | |
Support data encryption, multi-cast, port VLAN, separation, RSTP, etc; | |
Support Dynamic Bandwidth Allocation (DBA); | |
Support ONU auto-discovery/link detection/remote upgrade of software; | |
Support VLAN division and user separation to avoid broadcast storm; | |
Support various LLID configuration and single LLID configuration; | |
Different user and different service could provide different QoS by means of | |
different LLID channels; | |
Support power-off alarm function, easy for link problem detection; | |
Support broadcasting storm resistance function; | |
Support port isolation between different ports; | |
Support ACL and SNMP to configure data packet filter flexibly; | |
Specialized design for system breakdown prevention to maintain stable system; | |
Support dynamic distance calculation on EMS online; | |
Support RSTP, IGMP Proxy. |
FTTH GEPON OLT Physical Specifications:
Dimension(L*W*H) | 442mm*200mm*43.6mm | ||
Weight | 4.2kg | ||
Power Supply | 220VAC | AC:90~264V, 47/63Hz | Double Hot Backup |
Power Consumption | 30W | ||
Operating Environment | Working Temperature | -10~+55℃ | |
Storage Temperature | -40~+85℃ | ||
Relative Humidity | 5~90%(non-conditioning) |
FTTH GEPON OLT Delivery Ways:
Delivery way: By international express like UPS, Fedex, DHL, TNT, etc. Or by train, by sea, or by air, etc;
