Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of sc apc connector bundle fiber optical pigtail lszh 12 color in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
SC APC Connector Bundle Fiber Optical Pigtail LSZH 12 Color
The SC/APC 12 color bundle fiber pigtail is set for FTTH system,CATV System, LAN System, WAN System. It is with high and stable optical performance. Convenient for fiber splice, flexible for installation.
|
Item |
SM(Single Mode) |
MM(Multimode) | |||
|
Fiber Cable Type |
G652D/G655/G657A1/G657A2 |
OM1 |
OM2/OM3/OM4 |
||
|
Fiber Diameter (um) |
9/125 |
62.5/125 | 50/125 | ||
|
Cable OD (mm) |
0.9/1.6/1.8/2.0/2.4/3.0 |
||||
|
Endface Type |
PC |
UPC |
APC |
UPC |
UPC |
|
Typical Insertion Loss (dB) |
<0.2 |
<0.15 |
<0.2 |
<0.1 |
<0.1 |
|
Return Loss (dB) |
>45 |
>50 |
>60 |
/ |
|
|
Insert-pull Test (dB) |
<0.3 |
<0.2 |
<0.15 |
||
|
Interchangeability (dB) |
<0.1 |
<0.15 |
<0.1 |
||
|
Temperature Range (℃) |
-40~+80 |
||||
Corning/YOFC Fiber
CCTC Ceramic ferrule
Our brand confidence comes from a strong production team
Products Features
Good durability
Good exchangeability
High temperature stability
Low insertion loss and back reflection loss
Superior Quality Standard PC/UPC/APC Polishing
Can Reach Grade B
Insert-pull, key-oriented coupling mechanism which allows high repeatable, low-loss connection
APC/PC/UPC end face polish
Comply with Telcordia GR-326-CORE Specification
Applications
Gigabit Ethernet
FTTX applications
CATV
WANs
100% Strictly Tested Before Delivery
IL RL Test
3D tested by Daisi
End-surface
Temperature Test
Certificates
CE
CPR
ISO
RoHS
Full Ranges Of Reliability Tests From Third-party Lab
Coupling Test
Drop Test
Durability Test
High-Constant Temperature and Humidity Test
High-Low Temperature Test
Loss Test
Micro Cross Section Inspection Test
Resistant to Repeated Bending Test
Single Vertical Burning Test
Temperature Change Test
UV Test
7-15 days
How we can stand by you
Quick response within 24 hours
One-to-one consulting Service
Professional technical team support (RL can even reach 85dB/ Grade B connectors)
Super strict quality control (Real 1000 times plug experiment)
Huge production capacity
Never change prices arbitrarily
