Figure 8 GYTC8S Fiber Cable Self-support

Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of figure 8 gytc8s fiber cable self-support in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.

Figure 8 GYTC8S Fiber Cable Self-support

The structure of GYTC8S optical cable is that 250μm optical fiber is sheathed in a loose tube made of high modulus material, and the loose tube is filled with a waterproof compound. The center of the cable core is a metal reinforcement core (also non-metallic, such as FRP, etc.), and the loose tube (and filler rope) is twisted around the center reinforcement core to form a compact circular cable core. In the form of longitudinal wrapping, a layer of plastic-coated aluminum tape (APL) is added to the outer sheath of the cable core, and finally the polyethylene sheath is extruded together with the steel strand to make the cross-section be an "8" shape.

Place of Origin: Shenzhen, China

Brand Name: OPTICO

Model Number: GYTC8S

Number of Conductors: ≥ 10

Strength number: Corrugated Steel wire

Loose tube: PBT

Applicable mode: Single Mode and Multi Mode

Suspension wire material: steel wire strand

Sheath Material: PE

Return loss: >40dB

Insert loss: <0.1dB

Application:Aerial

Temperature range: -20°~60°C

Product Name: Figure 8 GYTC8S Stranded Loose Tube Outdoor Optical Fiber

Supply Ability: 3000 km/month

Packaging Details: 2km/fumigated wooden drum, or as required

Port: Shenzhen

Features:

High tensile strength of stranded wires meet the requirement of self-supporting and reduce the installation cost.

Good mechanical and temperture performance

High strength loose tube that is hydrolysis resistant.

sepcial tube filling compound ensure a critical protection of fiber.

The following measures are taken to ensure the cable watertight.

steel wire used as the central strength member,

loose tube filling compound

100%cable core filling

Applications:

Apply to Long distance communication system

Local area network system and Subscriber network system

Parameters:

Structure Specification:

Certificates:

Workshop:

Keywords: GYTC8S fiber cable, self-support, armored optical cable;
