3 port PM Circulator 1550nm
The 1550nm three-port polarization-maintaining (PM) optical circulator provided by OPTICO is a high-precision and high-stability passive optical component, designed for fiber optic systems that require polarization maintenance, low loss, and directional isolation. This circulator is engineered to enable unidirectional signal transmission, ensuring that light flows in a specific direction between the three ports, making it especially suitable for fiber optic sensing, laser systems, and high-performance communication systems. The 1550nm PM optical circulator enables unidirectional light transmission between three ports while maintaining the stability of the light's polarization state, ensuring minimal loss as the signal is transmitted along the slow axis. This device effectively isolates reflected light and reduces return loss, providing a high-performance solution for various fiber optic applications.
Product Specifications
| Wavelength Range | 1550nm |
| Isolation | ≥40dB |
| Insertion loss | ≤0.9 |
| Return loss | ≥50dB |
| Directivity(1~3) | ≥50dB |
| Extinction Ratio | ≥25dB |
| Max Optical Power | 300mW |
| Operating Temperature | -5~70℃ |
| Storage Temperature | -40~+85℃ |
| Operating Relative Humidity | 20 to 80% |
Highlight Features
Port 1 → Port 2: The light signal travels from Port 1 to Port 2.
Port 2 → Port 3: The light signal then travels from Port 2 to Port 3.
Port 3 → Port 1 (typically unused): This path is generally avoided to prevent unnecessary back reflections.
- Low Insertion Loss: Typical insertion loss is below 1 dB
- High Isolation: Isolation is typically above 40 dB, effectively preventing reverse interference between ports and ensuring unidirectional signal flow.
- High Stability: 1550nm wavelength offers enhanced stability against temperature and environmental variations, making it suitable for long-distance fiber transmission applications.
Can be configured with multiple connector types (such as FC/APC, FC/PC, SC/APC, etc.) to meet the specific needs of users.
OPTICO provides a variety of models of 1550nm PM optical circulators, supporting customized services with different package sizes, wavelength bandwidths and power levels.
- Add-Drop Multiplexing
- Fiber Optic Sensors
- Bidirectional Pumping Bidirectional Signal Transmission Systems
- Coupling In-Line Dispersion Compensation Devices
Applications
Circulators can also be used to send optical signal in two directions down a single fiber. A circulator is located at both ends of the fiber. Each circulator functions to add a signal in one direction while removing the signal in the other. See the example as below.
Certificates
Delivery(7-15 Days)
OPTICO offers a range of reliable delivery options, including air freight, sea freight, land freight, and express shipping through trusted providers like FedEx, DHL, and UPS. Whether you need speed, cost-effectiveness, or flexibility, OPTICO has got you covered. Trust OPTICO to get your products where they need to go, safely and on time.
How We Can Stand By You
Hot Tags: 3 port pm 1550nm circulator, China, manufacturers, suppliers, factory, wholesale, customized
Main Specification
| Wavelength Range | 1550nm |
| Isolation | ≥40dB |
| Insertion loss | ≤0.9 |
| Return loss | ≥50dB |
| Directivity(1~3) | ≥50dB |
| Extinction Ratio | ≥22dB |
| Max Optical Power | 300mW |
| Operating Temperature | -5~70℃ |
| Storage Temperature | -40~+85℃ |
| Operating Relative Humidity | 20 to 80% |
