Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of fc apc optic patch cord in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
FC APC Optic Patch Cord
The FC connector was first developed by Japan NTT. FC is an abbreviated form of Ferrule Connector. The connector is round with thread. It adopts the external reinforcement method of metal sleeve. The fastening method is screw buckle. It is generally used on the ODF side (the most used on the distribution frame). The connector has a simple structure, convenient operation and easy manufacture. At the same time, it uses metal joints, compared with plastic joints, FC joints can be plugged more times. Later, the FC connector was further improved by using a spherical pin (PC) with a mating end face, which greatly improved the insertion loss and return loss performance. As with other types of connectors, FC fiber connectors also have three grinding methods, namely PC, UPC and APC.
Product Specifications
| Single mode | Multimode | |
| Insertion Loss | IL<=0.3dB(PC); | ≤0.25dB |
| Return Loss | ≥50dB(PC) | |
| Durability | ≤0.2dB typical change, 1000 matings | |
| Interchangeability | ≤0.2dB | |
| Tensile strength | >70N | |
| Operating Temperature | -40°C to +85°C | -20°C to +70°C |
Corning/YOFC Fiber
CCTC ceramic ferrule
As with other types of connectors, FC fiber connectors also have three grinding methods, namely PC, UPC and APC.
Among them, PC is microsphere grinding and polishing, and its joint section is flat, often used in multi-mode, and is most widely used in telecommunication operator equipment.
UPC has less attenuation than PC and is often used in single mode. In order to improve the index of ODF equipment itself, some foreign manufacturers often use FC / UPC as the fiber jumper inside the ODF frame.
APC is a slanted connector, which is widely used in radio and television and early CATV, only for single mode. This kind of joint adopts the angled end face, which can improve the quality of the TV signal to a certain extent.
OPTICO provides FC connector jumpers. Compared with traditional fiber jumpers, OPTICO has the following characteristics:
For the structure of metal joints, it is necessary to screw the nut onto the adapter, which is firm, not easy to fall out, and prevent dust from entering.
Strong compatibility, can be used in optical fiber communication system, optical fiber broadband access network, CATV, optical fiber instrument table, optical fiber sensor, test equipment and other applications.
The use of advanced grinding technology allows the optical fiber connector to achieve a tight coupling state when docked with the device, and the transmission is more stable and reliable.
Low insertion loss, large return loss, strong tensile performance, good repeatability and uniformity.
The testing standards are strict, and each connector will undergo strict real-machine testing and quality inspection before leaving the factory to ensure that the fiber is used normally and there are no stains or scratches on the end surface.
We provide optical fiber patch cords for OEM product customization services. Length, color, connector type, label, etc. can be customized to meet your different needs.
Our brand confidence comes from a strong production team
Scenes of applications
LANs
WANs
CATV
100% Strictly Tested Before Delivery
IL RL Test
3D tested by Daisi
End surface test
Temperature test
Certificates
CE
CPR
ISO
RoHS
Full Ranges Of Reliability Tests From Third-party Lab
Coupling Test
Drop Test
Durability Test
High-Constant Temperature and Humidity Test
High-Low Temperature Test
Loss Test
Micro Cross Section Inspection Test
Resistant to Repeated Bending Test
Single Vertical Burning Test
Temperature Change Test
UV Test
How we can stand by you
Quick response within 24 hours
One-to-one consulting Service
Professional technical team support (RL can even reach 85dB/ Grade B connectors)
Super strict quality control (Real 1000 times plug experiment)
Huge production capacity
Never change prices arbitrarily
