Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of 8f mtp mpo to sc apc breakout cable in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
Product Profile
The 8F MTP MPO To SC APC Breakout Cable offers a simple and reliable solution for various connectivity needs, ensuring durability, flexibility, and safety in diverse network applications. There are various categories of MTP/MPO connectors, and they can be differentiated based on the number of cores (fiber arrays), polarity, gender (male or female), and end-face type (PC or APC). The male MPO/MPO fiber patch cable features two guide pins on the connector, whereas the female MPO/MPO fiber patch cable lacks pins. Precise alignment between MTP/MPO connectors is achieved through PIN pins, and when connecting two MPO connectors, one must be male, and the other must be female.
The overall length of the MTP/MPO breakout cable, as well as branch length and other specifications, can be tailored to meet the specific requirements of customers. All types of MTP/MPO breakout cables adhere to Telcordia-GR-326, IEC standards, and RoHS requirements.
Product Specifications
| Physical Properties | Parameter |
| Fiber Count | 8 Fibers |
| Fiber Mode |
OS2 |
| Connector Type | Connector A: US Conec MTP/OPTICO MPO; |
| Connector B: LC/SC/FC/ST | |
| Polarity | Type A/B/C |
| Cable Jacket | PVC/LSZH/OFNP |
| Jacket Colour | Yellow |
| Cable Diameter(mm) | 3.0 |
| Minimum Bend Radius | 7.5 |
| Fiber and Boot Length | Customizable |
| Optical Properties | Parameter | ||
| Insertion Loss(dB) | Standard Loss | Low Loss | Ultra Low Loss |
| ≤0.5 | ≤0.35 | ≤0.25 | |
| Return Loss(dB) | ≥35 | ||
| Wavelength(nm) | 1310/1550 | ||
| Tensile Strength(N) | Long Term | Short Term | |
| 70 | 220 | ||
| Operating Temperature(°C) | -40 ~ +85 | ||
| Storage Temperature(°C) | -20 ~ +70 | ||
Product Features
Breakout Cable boasts a distinctive design, featuring an MTP MPO connector at one end and multiple LC, SC, ST connectors in duplex or simplex configuration at the other. With fiber core options ranging from 8 to 144 cores, this breakout cable caters to a diverse range of connectivity needs. Its adaptability extends to both single-mode and multimode fiber, making it an ideal choice for network conversions spanning 10G-40G, 25G-100G, and 100G-400G.
The 8F MTP MPO To SC APC Breakout Cable is crafted from high-grade Corning/YOFC optical fiber renowned for its exceptional bending resistance and compression resistance. This prevents breaking and extends its overall service life, ensuring consistent performance over time.
The cable's robust tensile strength(70N~220N) allows for tighter cable bends, facilitating efficient slack storage and routing while maintaining durability. The outer jacket can be plenum-rated (OFNP), providing fire resistance and emitting low smoke to minimize potential damage in the event of combustion.
Featuring a vibrant yellow outer jacket, this cable allows for fast and easy identification in crowded switch or patch panel environments. The OS2-rated cable further distinguishes itself with a yellow jacket, identifying it as single-mode and minimizing the risk of accidental disconnection in densely populated installations.
Applications
High Density Data Center
Backbone Network
Optical Module Connection
Certificates
CE
CPR
ISO
RoHS
Full Ranges Of Reliability Tests From Third-party Lab
Coupling Test
Drop Test
Durability Test
High-Constant Temperature and Humidity Test
High-Low Temperature Test
Loss Test
Micro Cross Section Inspection Test
Resistant to Repeated Bending Test
Single Vertical Burning Test
Temperature Change Test
UV Test
Delivery(7-15 Days)
OPTICO offers a range of reliable delivery options, including air freight, sea freight, land freight, and express shipping through trusted providers like FedEx, DHL, and UPS. Whether you need speed, cost-effectiveness, or flexibility, OPTICO has got you covered. Trust OPTICO to get your products where they need to go, safely and on time.
How We Can Stand By You
Quick Response within 24 Hours
Quick Response within 24 Hours
Professional Technical Team Support
Professional Technical Team Support
Huge Production Capacity
Never Change Price Arbitrarily
FAQ
Q: Does the cable support efficient slack storage and routing?
Q: Can it be used in applications requiring low smoke emission?
Q: What is the tensile strength range of the cable?
