Product Profile
Featuring the MPO connector, a member of the MT series connectors, MPO To LC Fan Out Cable incorporates two guide holes and guide pins.
These components of MPO To LC Fan Out Cable enable accurate alignment and secure connections, minimizing signal loss and ensuring optimal performance.
MPO To LC Fan Out Cable is crafted using top-notch materials and advanced manufacturing techniques, guaranteeing durability and longevity.
MTP breakout cable is available in various configurations, tailored to specific application requirements.
MTP breakout cable offers flexibility and compatibility, allowing seamless integration into existing network infrastructures.
Product Specifications
| Physical Properties | Parameter | ||
| Fiber Count | 8/12/16/24/32/48 Fibers / Custom | ||
| Fiber Mode | SM(OS2)/MM(OM3/OM4/OM5) | ||
| Connector Type | Connector A: US Conec MTP Female/Male; MPO Female/Male | ||
| Connector B: LC/SC/FC/ST | |||
| Polarity | Type A/B/C | ||
| Cable Jacket | PVC/LSZH/OFNP | ||
| Jacket Colour | Yellow/Aqua/Magenta/Lime Green/ Custom | ||
| Cable Diameter(mm) | 3 | ||
| Minimum Bend Radius | 7.5 | ||
| Fiber and Boot Length | Customizable | ||
|
|
|||
| Optical Properties | Parameter | ||
| Insertion Loss(dB) | Standard Loss | Low Loss | Ultra Low Loss |
| ≤0.7 | SM ≤0.35, MM ≤0.5 | ≤0.25 | |
| Return Loss(dB) | SM ≥ 60, MM ≥ 20 | ||
| Wavelength(nm) | SM 1310/1550, MM 850/1300 | ||
| Tensile Strength(N) | Long Term | Short Term | |
| 70N | 220N | ||
| Operating Temperature(°C) | -40 ~ +85 | ||
| Storage Temperature(°C) | -20 ~ +70 | ||
Product Features
Seamless Connectivity
The MPO To LC Fan Out Cable enables seamless connectivity between MPO and LC connectors, eliminating compatibility issues and simplifying network installations.
Enhanced Performance
With its precise alignment and a low insertion loss of 0.35dB, the MPO To LC Fan Out Cable optimizes signal transmission, resulting in improved overall network performance.
MTP fanout cable delivers reliable and high-quality data transmission, minimizing signal degradation and maximizing network efficiency.
Easy Integration
The cable's compatibility and flexibility allow for easy integration into existing network infrastructures.
MTP fanout cable can be seamlessly incorporated into various network setups, minimizing disruptions and simplifying network upgrades or expansions.
Application Versatility
The MPO To LC Fan Out Cable caters to a wide range of applications, including data centers, telecommunications, and high-density environments.
MTP fanout cable offers a reliable and efficient solution for diverse network requirements, ensuring optimal connectivity and performance.
Our Brand Confidence Comes from a Strong Production Team
Applications
8-core MTPMPO branch fiber jumper realizes direct connection from 40G SR4 to 10G SR
12-core MTPMPO backbone jumper and 40G adapter panel realize 10G to 40G network upgrade
40G SR4 and 12-core MTPMPO trunk fiber jumper directly
100% Strictly Tested before delivery
IL/RL test
3D test
Polarity test
Production Drawing
OPTICO owns a powerful team of engineers, production instruction drawings, logos, colors, connectors, the number of cores, and other special requirements can be customized.
Welcome to contact us to customize your special requirements.
Connectivity Solutions
10G Trunk Cabling Solution
1. Core Cabling Solution:
a. Core Connection Equipment:
In the core connect, a Switch is Equipped with the 10G SFP+ 300m 850nm Optical Transceiver Module to send and receive signals. These modules enable data transmission speeds of up to 10 Gbps, with a maximum transmission distance of 300 meters, making them suitable for data centers and large network environments.
b. Fiber Connection Method：
Connectivity is established using of LC UPC to LC UPC Duplex OM4 Multimode Patch Cord or MTP to LC 12F Bundle Patch Cable.
c. Fiber Cabling Management:
24F 2×12F MPO-6LC MPO Cassette, containing 24 LC duplex modules, is utilized along with a 1U high-density fiber enclosure. This setup optimizes fiber management and minimizes cable clutter.
2. Core to Access Connection:
16F MPO-MPO Female Trunk Cable OM3 or 12F MTP MPO Fiber Cable can be used to contact the core connection and access cabling.
3. Access Cabling Solution:
The same connection approach of the core can also be applied to the access cabling solution, ensuring scalability and consistency throughout the network.
Certificates
CE
CPR
ISO
RoHS
Full Ranges Of Reliability Tests From Third-party Lab
Coupling Test
Drop Test
Durability Test
High-Constant Temperature and Humidity Test
High-Low Temperature Test
Loss Test
Micro Cross Section Inspection Test
Resistant to Repeated Bending Test
Single Vertical Burning Test
Temperature Change Test
UV Test
Purchase Guide
| Polarity | Connector type | End surface | Fiber count | Length |
| A | MPO Female | UPC | 8 | 1m |
| B | MPO Male | APC | 12 | 2m |
| C | MTP Female | 24 | 3m | |
| MTP Male | ... | ... | ||
| Custom | Custom |
Delivery(7-15 Days)
How We Can Stand by You
- Quick response within 24 hours
- One-to-one consulting Service
- Professional technical team support
- Super strict quality control
- Huge production capacity
- Never change prices arbitrarily
