1X8 Mini Metal Tube PLC Splitter
PLC optical splitter is a kind of optical power sharing product made by using planar optical waveguide technology on the basis of quartz substrate material. It is mainly suitable for coupling and distribution of optical signals in passive optical network (PON) systems. One of the most important passive components in the network; the PLC optical splitter provided by OPTICO has a variety of channels such as 1xN, 2xN, MxN, etc.,
|
Wavelength (nm) |
1260-1650 |
||||||||
|
Parameters |
1×4 |
1×8 |
1×16 |
1×32 |
1×64 |
2×4 |
2×8 |
2×16 |
2×32 |
|
Insertion Loss(with connector)(dB) |
≤7.4 |
≤10.7 |
≤13.7 |
≤16.9 |
≤21 |
≤7.8 |
≤11.5 |
≤14.5 |
≤17.7 |
|
Insertion Loss(W/O connector)(dB) |
≤7.7 |
≤11.2 |
≤14.2 |
≤17.5 |
≤21.5 |
≤8.3 |
≤12 |
≤15 |
≤18.2 |
|
Uniformity (dB) |
≤0.8 |
≤1.0 |
≤1.4 |
≤1.9 |
≤2.7 |
≤1.7 |
≤1.7 |
≤2.2 |
≤2.7 |
|
PDL(dB) |
≤0.3 |
≤0.3 |
≤0.3 |
≤0.3 |
≤0.4 |
≤0.2 |
≤0.4 |
≤0.4 |
≤0.4 |
|
Size(ABS bype) (H×W×L)(mm) |
10x80x100 |
18x80x120 | 18x115x140 | 10x80x100 | 18x80x120 | ||||
|
Return Loss(dB) |
>50 |
||||||||
|
Directivity(dB) |
>55 |
||||||||
|
Temperature Range(°C) |
-40~+75 |
||||||||
|
Storage Temperature(°C) |
-40~+85 |
||||||||
The inner structure of the 1X8 Mini Metal Tube PLC Splitter
Advantages of applications
Corning/YOFC/Customized fiber
High quality connector
(High RL and low IL)
High quality ceramic ferrule
(Low PDL)
Scenes of applications
FTTH Networks
DWDM and CWDM Systems
PON Networks
We have a strong production team
International/domestic certificates
CE
CPR
ISO
ROHS
7-15 DAYS
FAQ:
1, I want to visit your factory, and afterward some other factories in Shenzhen /Guangzhou /Dongguan, Can you accompany and guide for me?
We will try our utmost to make it most convenient for you.
2, We want to do our own packing, can you make the packaging for us?
Yes, OEM service are availble.
3, We want to take sample for quality testing, can you offer free sample?
Yes, free samples can be provided.
4, We require products with environment-friendly material, can you supply them?
Yes, of course. Our product meets ISO, CPR, CE, ROHS, Telcordia, UL certificate standards.
5, Can I customize the printing part on the terminal boxs?
Yes, you can decide the printing part content on the boxes.
