DAC QSFP+ to 4xSFP+
The QSFP+ to 4x SFP+ Passive cable assemblies are high performance, cost effective for SFP+ and QSFP+ equipment interconnects . The Hybrid cables are compliant with SFF-8436 and SFF-8431specifications. It is offer a low power consumption，short reach interconnect applications. The cable each lane is capable of transmitting data at rates up to 10Gb/s ,providing an aggregated rate of 40Gb/s.
Features:
Hybrid cable conforms to the Small Form Factor SFF-8436 and SFF-8431
Support for multi-gigabit data rates :1.0 Gbps - 10.3125 Gbps (per channel)
Compliant with SFP MSA and SFF-8472
Maximum aggregate data rate: 41.25 Gbps (4 x 10.3125Gbit/s)
Hybrid cable link length up to 5m (passive limiting)
High-Density QSFP 38-PIN and 4x SFP 20-PIN Connector
RoHS compliant
Power Supply :+3.3V
Case operating temperature: Commercial: 0°C to +70°C
Applications
40G QSFP+ to 4×10SFP+
10G/40Gigabit Ethernet
InfiniBand SDR, DDR, QDR
Switches, Routers, and HBAs
Data Centers
Fibre Channel
One of our Busy factory office
Types of certificates to meet your request
Mission will be achieved in 7-15 days
All our products will through the industry test, so both the quality and the after-service,you will never worry about it in the future.
If interested,welcom to consult,yo know it's late to be your side.
