Product Profile
The 100G 16CH DWDM Mux Demux 1U Rack Mount is a high-density, low-loss passive DWDM device based on Gaussian AAWG for long-distance transmission. The unit can be used as a multiplexer or a demultiplexer (mux/demux).
OPTICO offers 100G DWDM MUX & DEMUX modules with different input and output fibers such as single mode fiber, multi-mode fiber and polarisation-maintaining(PM) fiber, which can be selected to suit different applications. Custom frequency grids, fiber types, and connector options are also available.
Product Specifications
| Item | Parameter | ||
| Channels | 16CH | ||
| Operating Wavelength(nm) | C07~C22 | C46~C61 | |
|
Channel Spacing(Ghz) |
100G |
||
|
Transmission Band(nm) |
ITU±0.11 |
||
|
Transmission Band Insertion Loss(dB) |
≤4.2 |
||
|
Isolation(dB) |
Adjacent |
≥28 |
|
|
Non-adjacent |
≥38 |
||
|
Ripple(dB) |
≤0.5 |
||
|
Directivity(dB) |
≥50 |
||
|
Return Loss(dB) |
≥45 |
||
|
Polarization Dependent Loss(dB) |
<0.2 |
||
|
Polarization Mode Dispersion(ps) |
<0.1 |
||
|
Operating Temperature(°C) |
-20 ~ +75 |
||
|
Storage Temperature(°C) |
-40 ~ +85 |
||
|
Max Optical Power(mW) |
300 |
||
|
Package Size (mm) |
L484*H250*D44 |
||
|
Fiber Type |
G657A1 |
||
|
Connector |
LC/UPC |
||
Product Features
- Minimized Signal Interference
Leveraging thin-film filter technology and high wavelength stability, the 100G 16CH DWDM Mux Demux boasts low polarization-dependent loss<0.2dB and high channel isolation. Its flat and wide passband ensures efficient signal transmission.
- Compact 1U Rack Mount Design
The 100G 16CH DWDM Mux Demux 1U Rack Mount is designed to fit within a standard 1U rack space, which is a common form factor in data center and networking environments. The compact size ensures that it can be easily integrated into existing rack configurations without the need for extensive modifications.
- Industry Standards Compliance
The epoxy-free optical path of DWDM module adheres to key industry standards, including Telcordia GR-1209-CORE, Telcordia GR-1221-CORE, ITU-T G.694.1, and ROHS compliance.
- Comprehensive DWDM Mux/Demux/OADM Functionality
The 100G 16CH DWDM Mux Demux 1U Rack Mount seamlessly combines the essential functionalities of DWDM, serving as a Multiplexer (Mux), Demultiplexer (Demux), and supporting Optical Add-Drop Multiplexer (OADM) capabilities. The multifunctional design optimizes network architecture, enhancing overall performance and efficiency.
- Versatile Integration for Varied Services
The 100G 16CH DWDM Mux Demux 1U Rack Mount provides flexibility to blend 1G/10G/25G/40G/100G/200G Ethernet, 8G/16G Fibre Channel (FC), Storage Area Network (SAN), Optical Transport Network (OTN), Synchronous Digital Hierarchy/Synchronous Optical Networking (SDH/SONET), and native video services.
Applications
Data Center
PON Network
DWDM System
