Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of 400g 16f-2x8f mtpf fiber trunk cable in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
The 400G 16F-2X8F MTPF Fiber Trunk Cable is a high-performance, high-density solution essential for modern data centers and high-speed network environments. Designed with a TIA-568 Type B polarity configuration, it features one 16-fiber MTP/APC (SM) connector on Side A and two 12-fiber MTP/UPC (MM) connectors on Side B, ensuring flexible and reliable connectivity.
Built with premium Corning® OMA® bend-insensitive fiber and high-quality MTP connectors, this cable offers excellent durability and ease of installation in tight spaces. Its LSZH jacket provides enhanced safety in case of fire. With insertion loss ≤0.35dB and return loss ≥35dB, it delivers outstanding optical performance and supports a wide range of applications including 100G, 400G, and beyond.
An ultra-low loss version (≤0.25dB) is also available upon request, making it ideal for critical high-speed links such as 400G DR4/XDR4 and QSFP-DD deployments.
Specifications
|
Category |
Specification |
|
|
Product Name |
400G 16F-2X8F MTPF Fiber Trunk Cable |
|
|
Model Number |
OP-16F-MTPF-Y-ATU-FF-B |
|
|
Connector Configuration |
Side A：1x 16-Fiber MTP/APC (Elite Female), Single-Mode (SM) |
|
|
Side B：2x 12-Fiber MTP/UPC (Elite Female), Multi-Mode (MM) (OMA) |
||
|
Polarity Type |
TIA-568 Type B |
|
|
Fiber Type |
Corning® OMA® Bend-Insensitive Multi-Mode Fiber |
|
|
Fiber Count |
16 Fibers (Trunk) -> 2x 12 Fibers (Fan-out) |
|
|
Jacket Color |
Magenta LSZH |
|
|
Jacket Material |
LSZH (Low Smoke Zero Halogen) |
|
|
Fire Rating |
CPR-Dca |
|
|
Cable Diameter |
3.0 mm |
|
|
Insertion Loss(dB) |
Low Loss |
Ultra Low Loss |
|
≤ 0.35 |
≤ 0.25 |
|
|
Return Loss(dB) |
≥ 35 |
|
|
Operating Temperature(°C) |
-40°C to +85°C |
|
|
Storage Temperature(°C) |
-40°C to +85°C |
|
|
Pinout / Color Code |
Complies with TIA-598 standard. |
|
Applications
Direct High-Speed Transceiver Connection: The 400G 16F-2X8F MTPF Fiber Trunk Cable features MTP interfaces that can directly mate with 400G/100G optical transceivers, providing a plug-and-play parallel fiber channel for optical links and greatly simplifying deployment.
Pre-Terminated Structured Cabling Systems: Its "one-to-two" (16F to 2x12F) Type B polarity design is ideal for structured cabling between pre-terminated fiber patch panels, significantly reducing installation time and human error, while improving reliability and cable management cleanliness.
Features & Advantages
The 400G 16F-2X8F MTPF Fiber Trunk Cable provides high-density connectivity ideal for 400G high-speed transmission systems：
CORNING OMA fiber ensures stable performance.
LSZH jacket for fire safety and environmental friendliness.
Type B polarity design for broad compatibility and easy deployment.
Ideal for data centers, HPC, and high-speed network environments.
Why Choose This 400G 16F-2X8F MTPF Fiber Trunk Cable from OPTICO?
The 400G 16F-2X8F MTPF Fiber Trunk Cable is engineered for reliability and high performance in demanding data center environments. We use premium Corning® OMA® fiber and certified MTP connectors to ensure low insertion loss (≤0.35dB) and robust performance.
Every cable undergoes strict end-face inspection and IL/RL testing. Custom length, polarity, and jacket options (LSZH/CPR) are available.
With 15+ years of optical expertise, OPTICO offers fast turnaround and competitive pricing.
OPTICO Main Certificates
CE
CPR
ISO
RoHS
Prompt and diverse Delivery(7-15 Days)
OPTICO offers a range of reliable delivery options, including air freight, sea freight, land freight, and express shipping through trusted providers like FedEx, DHL, and UPS. Whether you need speed, cost-effectiveness, or flexibility, OPTICO has got you covered. Trust OPTICO to get your products where they need to go, safely and on time.
How We Can Stand By You
Quick Response within 24 Hours
One-to-one Consulting Service
Professional Technical Team Support
Super Strict Quality Control
Huge Production Capacity
Never Change Price Arbitrarily
After-sales Services
When you encounter problems with your optical network equipment or system, feel free to contact us and submit a service request via:
FAQ
Q: What is the 400G 16F-2X8F MTPF Fiber Trunk Cable used for?
A: It is designed for high-density data centers and enterprise networks, supporting 400G to dual 200G or lower-speed breakout applications.
Q: What type of fiber does this cable use?
A: It uses CORNING® OM5® multimode fiber, optimized for SWDM (short-wave wavelength division multiplexing).
Q: What connectors are on each side of the cable?
A: Side A has one 16F MTP/APC connector, and Side B has two 8F MTP/UPC connectors.
Q: Why is the LSZH jacket important?
A: The LSZH (Low Smoke Zero Halogen) jacket enhances safety by reducing smoke and toxic emissions in case of fire.
