Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of 8 channel ccwdm mux demux in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.

Product Profile

This 8 Channel CCWDM Mux Demux utilizes free-space optics technology and is a passive wavelength division multiplexing (WDM) device suitable for short-distance transmission, high density, and low loss. Integrating a multiplexer and demultiplexer, it enables efficient multiplexing and demultiplexing of 8 CWDM wavelength signals, supporting passive transparent multiplexing for any rate and any service without additional configuration, seamlessly adapting to the transmission needs of various service signals.

This CCWDM module is widely compatible with 1G/10G/25G Ethernet, multi-rate fiber channel, SDH/SONET, FTTx, and CATV services. Leveraging its passive transparent multiplexing characteristics, it can flexibly support various rate services without requiring additional signal processing. Furthermore,the 8 Channel CCWDM Mux Demux can be paired with CWDM optical modules and OADM modules to flexibly build diverse network topologies such as point-to-point and ring networks, offering flexible networking options and strong overall adaptability.

Compared to traditional CWDM, this CCWDM module has a more compact structure, higher integration, lower insertion loss, and superior optical path performance and channel consistency, effectively saving fiber optic cabling resources and enabling low-cost optical network expansion and upgrades.

Product Specifications

Parameter	4CH	8CH	16CH	18CH
Operating Wavelength(nm)	1260～1620
Channel Wavelength(nm)	1270,1290,...,1590,1610,or 1271,1291,...,1591,1611
Channel Spacing(nm)	20
Channels Passband(nm)	CWL+/-6.5nm
Insertion Loss (dB)	≤1.2	≤1.5	≤2.2	≤2.2
Channel Pipple(dB)	≤0.4
Adjacent Isolation(dB)	＞30
Non-adjacent Isolation(dB)	＞40
Polarization Mode Dispersion(ps)	≤0.2
Polarization Dependent Loss(dB)	≤0.2
Directivity(dB)	＞45
Retumn Loss(dB)	＞45
Maximum Power Handling(mW)	500
Operating Temperature(℃)	-5～70
Storage Temperature(℃)	-40～85
Fiber Type	G657A1 or Customized
Connector	Customized
Package Dimension(mm)	44×28×6.2		50×50×7
Remarks:
*1.All parameters are without connectors
*2.Connector Loss: 0.2dB/each added

Product Advantages

Multi-channel independent passband,

no crosstalk interference

Low insertion loss,

high isolation

Ultra-wide operating temperature range,consistent performance at high

and low temperatures

Single & Dual Fiber Options for Maximum Deployment Flexibility

Dual-fiber bidirectional transmission delivers higher bandwidth with stable and high-quality signal performance.

Meanwhile, the single-fiber bidirectional Mux/Demux solution enables simultaneous upstream and downstream signal transmission over one optical fiber, greatly reducing cabling costs and optimizing fiber resource utilization.

single fiber

dual fiber

Product Application

Metro WDM Systems

Data Center

Enterprise Networks

Access Networks

certificates

ISO

ISO

Patchcord-PLC-ROHS

ROHS

WDM-CE

CE

FAQ

Q: What is WDM?

A: WDM is a core optical communication technology for high-capacity inter-site transmission. It can simultaneously transmit multiple optical signals of different wavelengths in a single optical fiber, significantly improving network bandwidth.

Q: What are CCWDM?

A: CWDM, or Coarse Wavelength Division Multiplexing, is a cost-effective WDM transmission technology widely deployed in metro access networks. It features a wide channel spacing with a standard wavelength interval of 20 nm. CCWDM, Compact Coarse Wavelength Division Multiplexing, is the miniaturized and compact version of conventional CWDM.

Q: What are the differences between CWDM and CCWDM?

A: The core differences between CWDM and CCWDM are reflected in cascading structure, package size and insertion loss. Traditional CWDM adopts fiber cascading. Limited by the minimum bending radius of optical fibers, it features a larger overall package size and low space utilization, with a greater number of internal collimators. In contrast, CCWDM applies substrate integrated design, with collimators and filters integrally welded together. It realizes channel cascading through parallel light beams in free space without connecting cascade fibers, enabling miniaturized and compact packaging. Meanwhile, structural differences cause obvious loss deviation. CWDM has more coupling points and higher insertion loss, while CCWDM owns a simplified optical path and fewer optical components, delivering lower loss and more stable performance, making it ideal for high-density and space-limited cabinet wiring scenarios.

Hot Tags: 8 channel ccwdm mux demux, China, manufacturers, suppliers, factory, wholesale, customized, 1x8 CWDM Demux Mux Module, 6 Port CWDM, cisco dwdm mux, CWDM DWDM Fiber Mux Demux and OADM Modules, cwdm single mode fiber, Networks Fiber Optic CWDM LGX Module

Parameter	Unit	Value
Channels Number	-	2	4	8	16
Channel Space	nm	20
Central Wavelength	nm	1271~1611
Operating wavelength	nm	1260-1460 or 1460-1620 or 1260-1620
Passband	nm	λITU±6.5
Pass band Flatness	dB	≤0.5
Insertion Loss (Typ.)	dB	0.8	1.3	2.4	4.6
Insertion Loss (Max.)	dB	0.9	1.5	2.8	5.0
Adjacent Channel Isolation	dB	≥30
Non-adjacent Channel Isolation	dB	≥40
Polarization Mode Dispersion	ps	≤0.1	≤0.1	≤0.15	≤0.15
Polarization Dependent Loss	dB	≤0.1	≤0.15	≤0.2	≤0.25
Return Loss	dB	≥50
Directivity	dB	≥50
Insertion Loss Temperature Sensitivity	dB/°C	0.005	0.005	0.007	0.007
Wavelength Temperature Shifting	nm/°C	0.002
Operation Temperature	°C	-10~+70
Storage Temperature	°C	-40~+85
Package Dimension	mm	ABS box: 100X80X10mm or customized
