Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of cwdm multiplexer module in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
CWDM is a low-cost WDM transmission technology for the access layer of the metropolitan area network. In principle, CWDM uses an optical multiplexer to multiplex optical signals of different wavelengths into a single optical fiber for transmission. At the receiving end of the link, the mixed signal in the optical fiber is decomposed into different wavelengths by means of an optical demultiplexer. Signal, connect to the corresponding receiving device.
Parameter | 4 Channel | 8 Channel | 18 Channel | ||||
Mux | Mux | Demux | Mux | Demux | Mux | Demux | |
Channel Wavelength (nm) | 1270~1610 | ||||||
Center wavelength Accuracy (nm) | ±0.5 | ||||||
Channel Spacing (nm) | 20 | ||||||
Channel Passband (@-0.5dB bandwidth (nm) | >13 | ||||||
Insertion Loss (dB) | ≤1.6 | ≤2.5 | ≤3.0 | ||||
Channel Uniformity (dB) | ≤0.6 | ≤1.0 | ≤1.5 | ||||
Channel Ripple (dB) | 0.3 | ||||||
Isolation (dB) | Adjacent | N/A | >30 | N/A | >30 | N/A | >30 |
Non-adjacent | N/A | >40 | N/A | >40 | N/A | >40 | |
Inertion Loss Temperature Sensitivity (dB/°C) | <0.005 | ||||||
Wavelength Temperature Shifting (nm/°C) | <0.002 | ||||||
Polarization Dependent Loss (dB) | <0.1 | ||||||
Polarization Mode Dispersion | <0.1 | ||||||
Directivity (dB) | >50 | ||||||
Return Loss (dB) | >45 | ||||||
Maximum Power Handling (mW) | 300 | ||||||
Opterating Temperature (°C) | -5~+75 | ||||||
Storage Temperature (°C) | -40~85 | ||||||
Low loss
High channel isolation and low crosstalk
Can reach industrial garde
CE
ISO
ROHS
CWDM wavelengths range from 1260-1625nm, channel spacing is 20nm, which actually cover all the range of DWDM wavelengths (1470-1625nm). And DWDM wavelengths have much smaller channel spaces (0.4nm/0.8nm). Therefore, the CWDM wavelengths near
DWDM wavelengths can be used to transmit the DWDM wavelengths. In most practical applications, CWDM 1530nm channel is used to achieve hybrid CWDM & DWDM.
