Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of 12 cores mtp to st fiber optic patch cable in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
Product Profile
The 12 Cores MTP to ST Fiber Optic Patch cable is a cable assembly designed to connect MTP connectors on one end to ST connectors on the other end. MTP connectors are typically used for high-density applications, offering multiple fibers within a single connector. This offers seamless connection to patch panels and data distribution routing.
MTP/MPO cables are ideal for connecting high speed switches populated with such higher rate transceivers as QSFP+ transceivers to existing 10GbE elements populated with SFP+ modules.
Product Specifications
| Physical Properties | Parameter |
| Fiber Count | 12 Fibers |
| Fiber Mode |
Single-mode(OS2) |
| Connector Type | US Conec MTP/OPTICO MPO |
| Polarity | Type A/B/C |
| Cable Jacket | PVC/LSZH/OFNP |
| Jacket Colour | Yellow |
| Cable Diameter(mm) | 3.0 |
| Minimum Bend Radius | 7.5 |
| Fiber and Boot Length | Customizable |
| Optical Properties | Parameter | ||
| Insertion Loss(dB) | Standard Loss | Low Loss | Ultra Low Loss |
| ≤0.5 | ≤0.35 | ≤0.25 | |
| Return Loss(dB) | ≥35 | ||
| Wavelength(nm) | 1310/1550 | ||
| Tensile Strength(N) | Long Term | Short Term | |
| 70 | 220 | ||
| Operating Temperature(°C) | -40 ~ +85 | ||
| Storage Temperature(°C) | -20 ~ +70 | ||
Product Features
Crafted to meet the demands of modern connectivity, our MTP/MPO breakout cable undergoes rigorous 100% factory testing to ensure it meets the highest standards. Adhering to IEC-61754-7 and TIA-604-5 standards, this cable features MTP/MPO connectors on one end and LC/FC/SC/ST/MTRJ connectors on the other.
Featuring precision-molded MT ferrules, metal guide pins, and exacting outer shell dimensions, our MPO connectors ensure precise fiber alignment during docking. These connectors can be batch-terminated in combinations of 8, 12, 16 or 24 fiber ribbon cables, providing flexibility in deployment.
MTP to ST Fiber Optic Harness is available in both single-mode and multi-mode configurations, supporting 9/125, 50/125, and 62.5/125 fiber modes. Whether you require simplex or duplex cables, our customized design options cater to your specific needs. Available in configurations ranging from 12-core to 48-core, and even up to 144-core, we provide a comprehensive suite of options.
The MTP/MPO breakout cable caters to high-performance and rapid installation requirements of dense applications. Offering a smooth transition from multi-fiber cables to single-fiber or duplex connectors, this cable meets a variety of fiber cabling needs. The high-density MPO connectors offer a remarkable 12 times the density of standard connectors, leading to significant space and cost savings.
Applications
Certificates
CE
CPR
ISO
RoHS
Full Ranges Of Reliability Tests From Third-party Lab
Coupling Test
Drop Test
Durability Test
High-Constant Temperature and Humidity Test
High-Low Temperature Test
Loss Test
Micro Cross Section Inspection Test
Resistant to Repeated Bending Test
Single Vertical Burning Test
Temperature Change Test
UV Test
Delivery(7-15 Days)
OPTICO offers a range of reliable delivery options, including air freight, sea freight, land freight, and express shipping through trusted providers like FedEx, DHL, and UPS. Whether you need speed, cost-effectiveness, or flexibility, OPTICO has got you covered. Trust OPTICO to get your products where they need to go, safely and on time.
How We Can Stand By You
FAQ
Hot Tags: 12 Cores MTP To ST Fiber Optic Patch cable, China, manufacturers, suppliers, factory, wholesale, customized, mtp om4 patch cord, 12 fiber om4 cable, mpo fiber jumper, MTP MPO Patch Cable, om3 multimode fiber, mtp mtp jumper
