Shenzhen Optico Communication Co., Ltd. is one of the most credible manufacturers and suppliers of 1x128 mini type plc splitter in China. Please feel free to wholesale high quality customized products at competitive price form our factory. If you have any enquiry about free sample, please feel free to email us.
1x128 Mini Type PLC Splitter
With the gradual saturation of FTTH network construction, and the sinking of FTTH market. The market has gradually diversified requirements on the technology and shape of its core device, Fiber Splitter. Most importantly, in the realistic construction of various optical networks, the integration requirements for PLC Splitter are also getting better and better. In addition to small splitters such as 1x3/1x5/1x6/1x9/1x12 in FTTR/FTTB schemes proposed by current top telecom companies and large projects, end users prefer ultra-integrated Splittter such as 1x128 to reduce the average cost. Although people's requirements for the accuracy of data transmission are improved, the parameters of the product are also more and more refined, so there has been a 1x128 PLC Splitter in the market. as IL<22.7 dB, Uniformity<1.4dB, it was also confirmed by the information obtained from the OPTICO team's participation in the ECOC2022 Exhibition.
Based on this standard, OPTICO defines this standard as its internal Class A PLC Splitter, but it is also significantly more expensive. For the OPTICO 1x128 PLC Splittter, customers can choose between Grade A and Grade P. Please refer to the following parameter table for more details.
| Item | OPTICO 1x128 Mini Type PLC SPlitter | |
| A Grade | P grade | |
| Operating Wavelength(nm) | 1260-1650 | |
| Insertion loss(dB) | 22.7(without connector) | 23.8(without connector) |
| Uniformity(dB) | ≤1.4(without connector) | ≤4(without connector) |
| PDL(dB) | <0.3 | |
| Return loss(dB) | >55 | |
| Directivity(dB) | >55 | |
| Fiber Type | G657A1 or as requested | |
| Fiber Connector | SC/APC or as requested | |
| Operating Temperature(℃) | -40~+85 | |
| Storage Temperature(℃) | -40~+85 | |
| Package Type(LxWxH) | 100*10*80/100*6*60 mm | |
Structure Diagram
Features
-
Low insertion loss and high return loss
-
PDL automatic screening system(Ultra low PDL is available)
-
High reliability and stability
-
Connector can up to grade B
-
100% 3D tested by Daisi and Sumix
-
High-low temperature cycle test
-
100% tested before delivery
-
FTTH Cabling solution could be design
Applications
