Product profile
The 16F MPO-MPO Male Trunk Cable OM3 is a top-tier optical fiber cable meticulously crafted to excel in data centers, enterprise networks, and high-speed connectivity scenarios.
The 16F MPO Trunk Cable OM3 has an insertion loss as low as 0.3 dB and a return loss of up to 20dB, minimizing signal attenuation and ensuring high-performance data transmission in data centers.
The 16F MPO Trunk Cable OM3 is equipped with a high-quality MPO Plus connector, which is known for its excellent quality and performance.
OPTICO provides a variety of outer sheath materials such as LSZH/OFNP/OFNR to choose from, with good flame retardancy and a service life of up to 20 years.
Customers can also customize freely.
Product specifications
| Physical Properties | Parameter |
| Fiber Count | 16 Fibers |
| Fiber Mode |
OM3 |
| Connector Type | MPO Male |
| Polarity | Type A/B/C |
| Cable Jacket | PVC/LSZH/OFNP |
| Jacket Colour | Aqua |
| Cable Diameter(mm) | 3.0 |
| Minimum Bend Radius | 7.5 |
| Fiber and Boot Length | Customizable |
| Optical Properties | Parameter | ||
| Insertion Loss(dB) | Standard Loss | Low Loss | Ultra Low Loss |
| ≤0.5 | ≤0.35 | ≤0.25 | |
| Return Loss(dB) | ≥35 | ||
| Wavelength(nm) | 850/1300 | ||
| Tensile Strength(N) | Long Term | Short Term | |
| 70 | 220 | ||
| Operating Temperature(°C) | -40 ~ +85 | ||
| Storage Temperature(°C) | -20 ~ +70 | ||
Product Features
Space and Cost Efficiency
With the ability to achieve up to 16 times the density of SC connectors, the 16F MPO Male Trunk Cable OM3 significantly saves space and reduces costs.
This flexibility of 16F MPO Trunk Cable OM3 allows for seamless integration into different network environments and applications.
Customizable
The 16F MPO patch cord has different fiber modes, including (OS2, OM1, OM2, OM3, OM4, and OM5), and users can choose the most suitable option according to their specific requirements.
Extremely Low Insertion Loss and High Return Loss
16 Fiber MPO/MTP Patch Cord offers excellent optical performance with extremely low insertion loss and high return loss, maximizing signal integrity and reducing transmission errors.
Telcordia GR-1435-CORE Issue 2 Compliant
The trunk cable complies with the Telcordia GR-1435-CORE Issue 2 standard, which guarantees high-quality and reliable performance.
16F MTP trunk cable meets stand of IEC61753-1 with good mechanical.
applications
High Density Data Center
Backbone Network
Communication Rooms
Production Drawing
OPTICO owns a powerful team of engineers, production instruction drawings, logos, colors, connectors, the number of cores, and other special requirements can be customized.
Welcome to contact us to customize your special requirements.
Connectivity Solutions
100G Trunk Cabling Solution
1. Core Cabling Solution:
a. Core Connection Equipment: Deploy a high-performance switch and 100G QSFP28 Optical Transceiver Module for 100Gb/s speeds.
For short distances: use 100G-SR4-S 100m Optical Transceiver Module.
For long-distance: use 100G Fiber Optical SFP Transceiver 2KM, 100G LR4 QSFP 10km Optical Transceiver Module, or 100G QSFP28 Module Transceiver 40km.
b. Fiber Connection Method: Connect equipment using MTP Patch Cord Multimode 12 Cores.
c. Fiber Cabling Management: Implement 12 Port MTP Panel and high-density Optical MTP Panel for organized cable storage.
2. Core to Access Connection: Use 12F MTP MPO Fiber Cable to link the core and access.
Alternatively, we can also use 16F MPO-MPO Female Trunk Cable OM5 to connect Core and Access.
3. Access Cabling Solution: Identical to the core cabling solution.
delivery(7-15 days)
